2009-2017 Chevrolet Traverse 3.6L V6 | Power Steering Pump | 962403 - PHILTOP

2009-2017 Chevrolet Traverse 3.6L V6 | Power Steering Pump | 962403 - PHILTOP

Leak-Tested

Durable

4.4

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
36ISPSP1317US

Specifications

Brand
PHILTOP
Pulley Included
No
Reservoir Included
No
Pulley Attachment Type
Press-on
Outlet Connection Type
Threaded
Outlet Thread Size
16X1.5 in
Inlet Connection Type
Hose Barb
Drive Type
Engine
Material
Aluminium/Iron
Items Included
1x Power Steering Pump - 962403, 1x Manual
Warranty Period
2-Year
Part Number
962403

Highlights

  • Fitment:2008-2009 Equinox 3.6L, 2009 2010 2011 2012 2013 2014 2015 2016 2017 Traverse, [GMC], 2007-2016 Acadia, 2017 Acadia Limited, [Buick], 2008-2017 Enclave, [Saturn], 2007-2010 Outlook, 2008-2010 Vue 3.6L, [Suzuki], 2007-2009 XL-7, [Pontiac], 2008-2009 Torrent 3.6L
  • Reference Number: 962403、20954812、25939259、25964298、25897549、15285501、25775403、25803117、4910078J01、4910078J00、20976855, Condition: Brand New (Not Remanufactured); Pulley Included: No, Reservoir Included: No, Inlet Attachement Type:Hose Barb, Outlet Attachment Type: Threaded, Pulley attachment types: Press-on, Outlet inner diameter size: 16X1.5
  • Quiet Operation: Our power steering pump is designed to operate quietly, providing a smooth and comfortable driving experience.
  • Durable Design: Our power steering pump is built to last, with high-quality materials and expert craftsmanship.
  • Comfortable Experiences: Makes it easier and more stable for drivers to maneuver when they are more at ease. This significantly lessens tired driving

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2012 - 20132008 - 20112008 - 20112014 - 20172014 - 20172014 - 20172008 - 20092009 - 20172009 - 20172009 - 201620172011 - 20162010 - 201320162007 - 20162007 - 201620172008 - 20092007 - 20102007 - 20102008 - 20092008 - 20102007 - 20082007 - 20092007 - 20092008 - 2009
MakeBuickBuickBuickBuickBuickBuickChevroletChevroletChevroletChevroletChevroletGMCGMCGMCGMCGMCGMCPontiacSaturnSaturnSaturnSaturnSuzukiSuzukiSuzukiSuzuki
ModelEnclaveEnclaveEnclaveEnclaveEnclaveEnclaveEquinoxTraverseTraverseTraverseTraverseAcadiaAcadiaAcadiaAcadiaAcadiaAcadia LimitedTorrentOutlookOutlookVueVueXL-7XL-7XL-7XL-7
TrimBaseCXCXLConvenienceLeatherPremiumSportLSLTLTZPremierDenaliSLSLSLESLTBaseGXPXEXRRed LineXRBaseLimitedLuxuryPremium
Engine3.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V6
Note
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit
For warranty purposes it is recommended to always install a filter and to use suggested OE Fluid and flush the system;In-Line Filter available;Reservoir Not Included;with Seal Kit

How to Install?

Installation Manual Download

User manual (PDF)
Download

Primary Fault Code Analysis

  • P0550-Power steering pressure sensor circuit — inspect the sensor connector and wiring.
  • P0551–P0553-Pressure sensor circuit range/performance or low/high input — check pressure, sensor signals, and wiring.
  • P0620-Generator control circuit — check the charging system and related wiring.
  • P0562-Low system voltage — check the battery, charging output, and power connections.

Codes alone do not confirm power steering pump failure. Definitions and diagnostic procedures vary by vehicle.

Checks Before Installation

  • Confirm fitment: Compare mounting points, pulley specifications, fluid ports, and any sensor connectors.
  • Inspect the system: Check fluid condition, hoses, seals, and the drive belt for leaks or damage.
  • Check the new pump: Inspect for shipping damage and confirm smooth pulley rotation where applicable.

Installation Steps

  • STEP 1 — Let the engine cool, disconnect the negative battery cable, and drain the power steering fluid.
  • STEP 2 — Photograph the belt routing and hose connections. Release belt tension and remove the belt from the pump.
  • STEP 3 — Disconnect hoses and any wiring. Cap open lines to keep out dirt, then remove the old pump.
  • STEP 4 — Clean or flush contaminated lines. Install the new pump with new specified seals and tighten fasteners to vehicle specifications.
  • STEP 5 — Reconnect hoses and wiring. Reinstall the belt with correct alignment and tension.
  • STEP 6 — Fill with the specified fluid and bleed the system using the vehicle-specific procedure. Never run the pump dry or hold the steering at full lock.

After Installation

  • Verify correct belt seating and secure hose connections.
  • With the engine idling, check for smooth steering assist without unusual noise or vibration.
  • Inspect the pump and lines for leaks.
  • Switch off the engine, allow the fluid to settle, and recheck the level.

Product Video

Product Description

Power Steering PumpPower Assist Pump

Reviews

4.4/5

Based on 5 reviews

560%
420%
320%
20%
10%

Chris_GearHead_345

06/21/2026

Arrived sooner than expected and the packaging was excellent. I had a question about the warranty, and customer service was very polite and clear. A good buying experience.

Brad_AutoParts_475

03/11/2026

Super fast shipping, got it the next day! The pump was well-protected in the box. I called with a question about the fluid level and the support team was super helpful. Great service.

FAQS

1.Power steering fluid low: Check oil tank level. 2. Air in the boost system: Check the oil for air bubbles. 3. Aging pipes and clip: Check the aging of low pressure pipe. 4. Rotational system issues: Check associated axle clearance except crankshaft

Please take the time to carefully verify if your vehicle is compatible with our offering.Please under the guidance of professionals, ensure a smooth and expert installation process. (Instructions not included)

Mismatched high-pressure interface size, aging of sealing ring or gasket. The low-pressure pipe is damaged or loosened: Check whether the oil pipe is loose after tightening the bolts, and whether the gasket or seal is deformed.
