2011-2015 Chevrolet Cruze 2.0L L4 | A/C Condenser w/Receiver Drier | OE#23305638/73794 - PHILTOP

2011-2015 Chevrolet Cruze 2.0L L4 | A/C Condenser w/Receiver Drier | OE#23305638/73794 - PHILTOP

Receiver Drier Included

Leak-Tested

Precision Fit

4.8

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
61ISEWL2477US

Specifications

Brand
PHILTOP
Refrigerant Type
R134A
Receiver Drier Included
Yes
Outlet Type
Block Fitting
Inlet Type
Block Fitting
Items Included
1x A/C Condenser - 7-3794
Material
Aluminum Alloy
Manufacturing Process
Machined
Quantity
1
Color
Silver
Warranty Period
2-Year
OE Number
23305638,22869501,13267649,13377763,22878897
Part Number
73794,3794C,4770795,40329,313794,2433187,SBC3794,KLI3794,1040970,203794,PC3794P,BES3794,4770855,713794,670800617,3794AM,NC3794B,35919

Highlights

  • COMPATABILITY: Air Conditioning Condenser Replacement for Chevrolet Cruze 2011-2015, for Chevrolet Malibu 2013-2015, for Chevrolet Impala 2014-2020, for Buick LaCrosse 2010-2016, for Buick Verano 2012-2017, for Cadillac XTS 2013-2019, for Chevrolet Cruze Limited 2016, for Buick Regal 2014-2017, for Chevrolet Malibu Limited 2016, for Buick Regal 2011-2013 2.4L, for Buick Cascada 2016-2019
  • REPLACEMENT: INCLUDES: 1 x A/C Air Conditioning Condenser with Drier. Replaces Part# 7-3794. The AC condenser can easily be located inside the engine bay in front of the radiator and can be accessed by removing a few covers and screws
  • EFFICIENT COOLING CAPACITY: Using light and thin aluminum tubes to maximize heat transfer without compromising strength. The air conditioner condenser can cool the air inside the car quickly, even in hot environments. This improves your comfort in the car, especially in summer and hot weather
  • STURDY CONSTRUCTION: Our automobile air conditioning condenser employs cutting-edge technology, capable of rapidly and effectively reducing the temperature inside the vehicle. It is crafted with high-quality materials and meticulous craftsmanship, possessing excellent durability and reliable performance, ensuring long-term stability in operation
  • FUNCTION: The A/C condenser is the hot side of an air conditioning system, liquefying the steam refrigerant while dissipating heat. If there is a bad noise and the cooling performance of the vehicle is simply reduced, or a leak in your condenser unit, then you should replace the air conditioning condenser unit. (Make sure you drain the refrigerant before replacing the condenser unit)

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2016 - 20192016 - 20192017 - 20192012 - 20162012 - 20162010 - 2011201020112011201020112010 - 2011201220122012 - 20162012 - 201620122012 - 201620162012 - 20132014 - 20172012 - 201720112014 - 20172014 - 20172012 - 20162016 - 20172012 - 20172012 - 20162012 - 20172013 - 20162016 - 201720132013 - 20192013 - 20192013 - 20192013 - 20192013 - 20162017 - 20192014 - 20192014 - 201620172014 - 20152011 - 201520152011 - 20152011 - 20152011 - 201520162016201620162016201620142014 - 20192015 - 20192014 - 20192014 - 201920202014 - 20162014 - 20162017 - 201920202013 - 20142013 - 20152013 - 20152013 - 20152013 - 20152013 - 2015201620162016
MakeBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickBuickCadillacCadillacCadillacCadillacCadillacCadillacCadillacCadillacCadillacChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevrolet
ModelCascadaCascadaCascadaLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseLaCrosseRegalRegalRegalRegalRegalRegalRegalVeranoVeranoVeranoVeranoVeranoVeranoXTSXTSXTSXTSXTSXTSXTSXTSXTSCruzeCruzeCruzeCruzeCruzeCruzeCruze LimitedCruze LimitedCruze LimitedCruze LimitedCruze LimitedCruze LimitedImpalaImpalaImpalaImpalaImpalaImpalaImpalaImpalaImpalaImpalaMalibuMalibuMalibuMalibuMalibuMalibuMalibu LimitedMalibu LimitedMalibu Limited
TrimBasePremiumSport TouringBaseBaseCXCXCXCXLCXLCXLCXSConvenienceConvenienceLeatherLeatherPremiumPremiumSport TouringTouringBaseBaseCXLGSPremiumPremiumSport TouringBaseConvenienceLeatherPremiumSport TouringTurboBaseLiveryLuxuryPlatinumPremiumPremium LuxuryVsport PlatinumVsport PremiumVsport Premium LuxuryDieselEcoLLSLTLTZEcoLLSLTLTLTZEcoLSLSLTLTLTLTZLTZPremierPremierEcoLSLTLTLTZLTZLSLTLTZ
Engine1.6L L41.6L L41.6L L42.4L L43.6L V62.4L L43.0L V63.6L V62.4L L43.0L V63.6L V63.6L V62.4L L43.6L V62.4L L43.6L V62.4L L43.6L V63.6L V63.6L V62.0L L42.4L L42.4L L42.0L L42.0L L42.4L L42.0L L42.4L L42.4L L42.4L L42.0L L42.4L L42.0L L43.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V63.6L V62.0L L41.4L L41.8L L41.8L L41.4L L41.4L L41.4L L41.8L L41.8L L41.4L L41.8L L41.4L L42.4L L42.5L L43.6L V62.5L L43.6L V63.6L V62.5L L43.6L V63.6L V63.6L V62.4L L42.5L L42.0L L42.5L L42.0L L42.5L L42.5L L42.5L L42.5L L4
Note
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
-
with Receiver Drier
with Receiver Drier
with Receiver Drier
-
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier
with Receiver Drier

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm the condenser matches the vehicle, refrigerant type, inlet and outlet fittings, mounting holes and receiver-drier configuration.
  • Inspect the condenser for bent fins, cracked tubes or shipping damage.
  • Confirm whether the vehicle uses R134a or R1234yf. These refrigerants are not interchangeable.
  • Have a qualified technician recover the refrigerant before disconnecting any A/C line.
  • Keep all refrigerant lines sealed to prevent moisture and dirt from entering the system.

Installation Steps

  • Step-1: Recover the refrigerant with approved equipment and disconnect the negative battery cable.
  • Step-2: Disconnect the refrigerant lines and cap every opening immediately.
  • Step-3: Remove the cooling fan, shroud and condenser mounting bolts as required.
  • Step-4: Remove the old condenser without damaging the radiator or refrigerant lines.
  • Step-5: Replace all opened refrigerant-line O-rings with new ones. Never reuse old O-rings.
  • Step-6: Replace the receiver drier or desiccant whenever required. If it is integrated into the condenser, install a condenser with a new receiver drier.
  • Step-7: Lightly lubricate new O-rings with the correct PAG oil, then hand-start the refrigerant fittings.
  • Step-8: Tighten all fittings and mounting bolts to specification. Reinstall the fan, shroud and electrical connections.
  • Step-9: Evacuate the system and perform a vacuum-hold test before charging.

After Installation

  • Charge the exact refrigerant type and specified amount listed by the vehicle manufacturer. Add only the specified type and amount of PAG oil.
  • Do not charge the system based only on pressure readings.
  • Check all fittings for refrigerant or oil leakage.
  • Run the A/C at maximum cooling and verify high-side and low-side pressures.
  • Confirm the cooling fan operates and the vent temperature drops normally.
  • Check that condenser airflow is unobstructed and no warning lights are present.

Product Description

CondenserCondenser

Reviews

4.8/5

Based on 6 reviews

583%
417%
30%
20%
10%

Nicole White

08/22/2026

Verified buyer

Very affordable and you will not find this cheaper ANYWHERE! My air is blowing colder than ever!!

Tracie

07/17/2026

Verified buyer

Seems to be built well. It was a perfect fit and is operating just as it should. I paired it with a Denso compressor and it has been cooling great for about 4000 miles now. I would buy this for another vehicle if I needed to change the ac system.
