2005-2010 Cadillac STS 4.6L V8 | Aluminum Water Pump | OE#12595614/1308020 - PHILTOP

2005-2010 Cadillac STS 4.6L V8 | Aluminum Water Pump | OE#12595614/1308020 - PHILTOP

Reliable Sealing

Efficient Cooling

High-Temperature Resistant

5.0

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
35ISEWP1157US

Specifications

Brand
PHILTOP
Water Pump Drive Type
Serpentine Belt
Pulley Included
No
Gasket or Seal Included
Yes
Housing Material
Aluminum
Fan Clutch Included
No
Hub Height
1.97 in/50.1 mm
Impeller Material
Steel
Impeller Rotation
Reverse
Impeller Vane Quantity
6
Includes Back Housing
No
Mounting Hole Quantity
5
Thermostat Included
No
Items Included
1x Water Pump - AW6239
Quantity
1
Warranty Period
2-Year
OE Number
12595614,19195149,12563631,25746579
Part Number
1308020,AW6239,42022,W2235M,WP2235,US8955,DP1306,PWP13152,T1198,942022,251669,NP1890,220914

Highlights

  • Water Pump Specifications: ① Housing Material: Aluminum; ②Impeller Material:Steel plate; ③ Pulley Included: No; ④Gasket / Seal Included: Yes; ⑤ Impeller Vane Quantity:6; ⑥Mounting Hole Quantity:5; ⑦Water Pump Drive Type: Serpentine Belt
  • Vehicle Fitment: Water pump compatible with 2005-2010 STS 4.6L, 2004-2009 XLR, SRX 4.6L, 2006-2009 STS 4.4L. Please Confirmed PhiltopConfirmedFit Before Ordering
  • Replace OE Number: 1308020, AW6239, WP2235, 42022, W2235M, US8955, 19195149, 12595614, 12563631, 25746579, DP1306, PWP13152, T1198, 942022, 251669, NP1890, 220914, 111133, CP6239, P2235, 99200, AWP2235, 512519, NP016239, 12235, WP3164A, 11400236, 20915, 556239, 58657, 5513152, 54308020, 251687, 20914, 181903, 252890, PWP2235
  • Premium Quality: This brand-new engine water pump is built to last. It features a high-strength pulley and advanced sealing for quiet, wear-resistant operation. It undergoes multiple factory sealing tests, effectively preventing coolant leakage. Manufactured in an IATF 16949 certified facility, it guarantees easy installation and dependable performance
  • Warm Tips: Please check whether the water pump is compatible with your vehicle before purchasing .Offers 2 year / 20,000 miles service. If you have any questions about automotive water pump, you can feel free to contact us.

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2004 - 20092005 - 20102008 - 20092006 - 20092004 - 20082008 - 20092006 - 2009
MakeCadillacCadillacCadillacCadillacCadillacCadillacCadillac
ModelSRXSTSSTSSTSXLRXLRXLR
TrimBaseBasePlatinumVBasePlatinumV
Engine4.6L V84.6L V84.6L V84.4L V84.6L V84.6L V84.4L V8
Note-------

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm vehicle fitment and compare the new pump with the original.
  • Inspect the pump, impeller, pulley, hoses, thermostat and drive belt for damage or wear.
  • Allow the engine to cool completely, disconnect the negative battery cable and drain the coolant safely.
  • Clean and inspect the mounting surface for corrosion, cracks or deformation.

Installation Steps

  • Step-1: Remove any covers, accessories, drive belt and pulley blocking access to the pump.
  • Step-2: Record the positions of different-length bolts, then remove the old pump.
  • Step-3: Thoroughly clean the mounting surface without scratching it.
  • Step-4: Always install a new gasket or sealing ring. Never reuse the old seal.
  • Step-5: Position the new pump, hand-start the bolts and tighten them gradually in a crisscross pattern to the specified torque.
  • Step-6: Reinstall the pulley, belt and removed components, then refill with the specified coolant.
  • Step-7: Bleed trapped air from the cooling system according to the vehicle service manual.

After Installation

  • Check all bolts, hose clamps, seals and belt alignment.
  • Start the engine and inspect for coolant leaks or abnormal pump noise.
  • Confirm the coolant temperature remains normal and the vehicle does not overheat.
  • Recheck the coolant level after the engine cools and top up if necessary.

Product Description

PHILTOP Engine Water Pump KitPHILTOP Engine Water Pump Kit

Reviews

5.0/5

Based on 4 reviews

5100%
40%
30%
20%
10%

Nancy_FirstCar_745

11/25/2025

Super quick shipping, got it in just a couple of days. The packaging was secure and protected the pump well. Customer service was top-notch, answered my email right away.

Emma_DailyCommute_870

01/01/2026

Install went smooth, no problems at all. It was a direct replacement for my old pump. Much better than some other aftermarket parts I've tried that needed extra tinkering.

FAQS

No FAQs have been added for this product yet.
