2001-2005 Honda Civic 1.7L | Aluminum Water Pump | OE#19200PLC003/AW9419 - PHILTOP

2001-2005 Honda Civic 1.7L | Aluminum Water Pump | OE#19200PLC003/AW9419 - PHILTOP

Reliable Sealing

Efficient Cooling

High-Temperature Resistant

4.3

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
15ISEWP0377US

Specifications

Brand
PHILTOP
Water Pump Drive Type
Timing Belt
Pulley Included
Yes
Gasket or Seal Included
Yes
Housing Material
Aluminum
Fan Clutch Included
No
Hub Height
2.22 in/56.40 mm
Impeller Material
Steel
Impeller Rotation
Reverse
Impeller Vane Quantity
7
Includes Back Housing
No
Mounting Hole Quantity
6
Pulley Outside Diameter
2.2 in/55.88 mm
Thermostat Included
No
Items Included
1x Water Pump - AW9419
Quantity
1
Warranty Period
2-Year
OE Number
19200PLC003,19200PLE005,19200PLMA01,19200PMEA01,PA10131
Part Number
AW9419,1352420,41115,WPH044,WP9207,US9419,W9207M,CP9419,19207,T1165,GWHO48A,941115,GWHO55A,NP1842

Highlights

  • Compatibility: Fit for Honda Civic 2001, Civic 2002-2005 L4 1.7L
  • Replace OE Number: US9419, AW9419, 1352420, 41115, WPH044, W9207M, WP9207, 19200PLE005, 19200PLC003, 19200PLMA01, 19200PMEA01, PA10131, CP9419, 941115, GWHO48A, 19207, GWHO55A, NP1842, T1165, 512151, WPH41, FP2529, HYT22033C, NP019419, 1463670, W1352420, AWP9207, 2186617, H47, 2668829, WP8161RP, 160060392, P1842, H46, A352420, 19200PLMA01R, P9207, NP5471, NP9277, PQ436, 54352420, PA1303, 122033, WP220, 5553626, HO2420, 16419, 1312271, 571597, 181646, PWP9207, DP198, 506811, 1AMWP00029, PA1109, ELGWP9419, NP1672A, 690616, J1514039, 559419, 20792, 01463670, 1WP9419
  • New: This brand-new engine water pump is built to last. It features a high-strength pulley and advanced sealing for quiet, wear-resistant operation. Manufactured in an IATF 16949 certified facility, it guarantees easy installation and dependable performance
  • Warm Tips: Before you order, please take a moment to double-check compatibility. Use the "Philtop Confirmed Fit" tool (top left of the page) to select your vehicle's Year, Make, and Model and hit "Check Fit". Or, carefully review the fitment list in the description. This simple step guarantees the right part and a smooth installation
  • Warranty: 1-Year / 20,000 miles Protection for Peace of Mind

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2001 - 20052001 - 200520052001 - 20052001 - 20052001 - 200520052004 - 2005
MakeHondaHondaHondaHondaHondaHondaHondaHonda
ModelCivicCivicCivicCivicCivicCivicCivicCivic
TrimDXEXEX Special EditionGXHXLXLX Special EditionValue Package
Engine1.7L L41.7L L41.7L L41.7L L41.7L L41.7L L41.7L L41.7L L4
Note
Timing Belt Should Be Replaced with Water Pump
Timing Belt Should Be Replaced with Water Pump
Timing Belt Should Be Replaced with Water Pump
Timing Belt Should Be Replaced with Water Pump
Timing Belt Should Be Replaced with Water Pump
Timing Belt Should Be Replaced with Water Pump
Timing Belt Should Be Replaced with Water Pump
Timing Belt Should Be Replaced with Water Pump

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm vehicle fitment and compare the new pump with the original.
  • Inspect the pump, impeller, pulley, hoses, thermostat and drive belt for damage or wear.
  • Allow the engine to cool completely, disconnect the negative battery cable and drain the coolant safely.
  • Clean and inspect the mounting surface for corrosion, cracks or deformation.

Installation Steps

  • Step-1: Remove any covers, accessories, drive belt and pulley blocking access to the pump.
  • Step-2: Record the positions of different-length bolts, then remove the old pump.
  • Step-3: Thoroughly clean the mounting surface without scratching it.
  • Step-4: Always install a new gasket or sealing ring. Never reuse the old seal.
  • Step-5: Position the new pump, hand-start the bolts and tighten them gradually in a crisscross pattern to the specified torque.
  • Step-6: Reinstall the pulley, belt and removed components, then refill with the specified coolant.
  • Step-7: Bleed trapped air from the cooling system according to the vehicle service manual.

After Installation

  • Check all bolts, hose clamps, seals and belt alignment.
  • Start the engine and inspect for coolant leaks or abnormal pump noise.
  • Confirm the coolant temperature remains normal and the vehicle does not overheat.
  • Recheck the coolant level after the engine cools and top up if necessary.
