2011-2012 Audi Q5 2.0L L4 | Tensioner | OE#06H903133G/39122 - PHILTOP

2011-2012 Audi Q5 2.0L L4 | Tensioner | OE#06H903133G/39122 - PHILTOP

Quiet Operation

Slip Resistant

Corrosion & Heat-Resistant Housing

4.7

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
60ISETB2657US

Specifications

Brand
PHILTOP
Pulley Included
Yes
Belt Included
No
Belt Type
V-Ribbed
Contact Surface
Smooth/Backside
Pulley Outer Diameter
2.76 in
Items Included
1x Engine Timing Belt Tensioner - 39122
Quantity
1
Warranty Period
2-Year
OE Number
06H903133G,06H903133F
Part Number
39122

Highlights

  • [Fitment]: PHILTOP Belt Tensioner with Pulley Replacement For ① Audi A4 Quattro 2010-2012, 2009 2.0T, Q5 2011-2012 2.0T, A5 Quattro 2011-2012, 2010 2.0T, A4 2009-2012, A5 2010-2012
  • [OE Reference Number]: 06H903133G, 39122, 06H903133F, 49454, Manufactured using the same or improved technology and quality materials as the original equipment manufacturer (OEM) components to ensure a factory match
  • [Labyrinth Seal Protection]: PHILTOP automatic drive belt tensioner assembly with pulley adopts labyrinth seal to protect internal components, meeting or exceeding the service life requirements of the original manufacturer
  • [Long service life]: The damping system tested hundreds of times absorbs extreme vibration to improve the life of the tensioner as well as belts and accessories
  • [Strong stability]: Torsion round spring design used in PHILTOP tensioner provides reliable and stable tension

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2009 - 201220092009 - 20122009 - 201220092010 - 20122010 - 20122010 - 20122011 - 20122011 - 2012
MakeAudiAudiAudiAudiAudiAudiAudiAudiAudiAudi
ModelA4A4A4 QuattroA4 QuattroA4 QuattroA5A5 QuattroA5 QuattroQ5Q5
TrimBaseCabrioletAvantBaseCabrioletCabrioletBaseCabrioletPremiumPremium Plus
Engine2.0L L42.0L L42.0L L42.0L L42.0L L42.0L L42.0L L42.0L L42.0L L42.0L L4
Note----------

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm the engine application, mounting holes, pulley size, groove count and tensioner-arm direction.
  • Inspect the pulleys for binding, looseness or abnormal bearing noise.
  • Check the tensioner arm for smooth movement, sufficient damping and fluid leakage.
  • Inspect the belt for cracks, glazing, frayed edges, contamination or stretching. Replace an aged or worn belt at the same time.
  • Disconnect the negative battery cable before installation.

Installation Steps

  • Step-1: Photograph or record the belt-routing path before removing the belt.
  • Step-2: Use a suitable breaker bar or long-handled tool to slowly release the tensioner. Do not pry against the tensioner arm.
  • Step-3: Remove the belt and tensioner, then clean the mounting surface.
  • Step-4: Position the new tensioner and tighten its mounting bolts to specification.
  • Step-5: Route the belt according to the recorded path and ensure every rib is fully seated in the pulley grooves.
  • Step-6: Slowly release the tensioner and recheck the complete belt path.

After Installation

  • Confirm the tensioner bolts are secure and the belt is correctly seated.
  • Start the engine and observe the belt tracking and tensioner movement.
  • Check for belt slipping, jumping, lateral movement or abnormal noise.
  • Confirm the alternator and all belt-driven accessories operate normally.

Product Description

1belt tensioner

Reviews

4.7/5

Based on 3 reviews

567%
433%
30%
20%
10%

Mike from Texas_181

01/09/2026

This tensioner looks really solid and well-made. It was a great price for the quality. My Audi is running smoothly again, and I'm happy I didn't pay dealership prices.

Tom_Handy_627

06/20/2026

Installed this on my Audi A4 and it was a breeze. Fit perfectly and no issues whatsoever. Definitely a good buy compared to the dealer.

FAQS

No FAQs have been added for this product yet.
