2009-2013 Honda Fit 1.5L | Tensioner | OE#31170RB0J01/39182 - PHILTOP

2009-2013 Honda Fit 1.5L | Tensioner | OE#31170RB0J01/39182 - PHILTOP

Quiet Operation

Slip Resistant

Corrosion & Heat-Resistant Housing

4.4

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
77ISETB2727US

Specifications

Brand
PHILTOP
Pulley Included
Yes
Belt Included
No
Belt Type
V-Ribbed
Contact Surface
Smooth/Backside
Pulley Outer Diameter
2.76 in
Items Included
1x Engine Timing Belt Tensioner - 39182
Quantity
1
Warranty Period
2-Year
OE Number
31170RB0J01,31170RB0J02
Part Number
39182

Highlights

  • [Fitment]: PHILTOP Belt Tensioner with Pulley Replacement For ① Honda Fit 2009-2012, 2013 1.5L
  • [OE Reference Number]: 31170RB0J01, 39182, 31170RB0J02, 31170RSJE01, 31170RE2E01, 31170RE2ZE010, 31170RE2E010M2, 31170RB0J012M1, 31170RB0J012, 31170RE2ZJ012M1, 31180RBOJ01, Manufactured using the same or improved technology and quality materials as the original equipment manufacturer (OEM) components to ensure a factory match
  • [Labyrinth Seal Protection]: PHILTOP automatic drive belt tensioner assembly with pulley adopts labyrinth seal to protect internal components, meeting or exceeding the service life requirements of the original manufacturer
  • [Long service life]: The damping system tested hundreds of times absorbs extreme vibration to improve the life of the tensioner as well as belts and accessories
  • [Strong stability]: Torsion round spring design used in PHILTOP tensioner provides reliable and stable tension

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2009 - 20132009 - 2013
MakeHondaHonda
ModelFitFit
TrimBaseSport
Engine1.5L L41.5L L4
Note--

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm the engine application, mounting holes, pulley size, groove count and tensioner-arm direction.
  • Inspect the pulleys for binding, looseness or abnormal bearing noise.
  • Check the tensioner arm for smooth movement, sufficient damping and fluid leakage.
  • Inspect the belt for cracks, glazing, frayed edges, contamination or stretching. Replace an aged or worn belt at the same time.
  • Disconnect the negative battery cable before installation.

Installation Steps

  • Step-1: Photograph or record the belt-routing path before removing the belt.
  • Step-2: Use a suitable breaker bar or long-handled tool to slowly release the tensioner. Do not pry against the tensioner arm.
  • Step-3: Remove the belt and tensioner, then clean the mounting surface.
  • Step-4: Position the new tensioner and tighten its mounting bolts to specification.
  • Step-5: Route the belt according to the recorded path and ensure every rib is fully seated in the pulley grooves.
  • Step-6: Slowly release the tensioner and recheck the complete belt path.

After Installation

  • Confirm the tensioner bolts are secure and the belt is correctly seated.
  • Start the engine and observe the belt tracking and tensioner movement.
  • Check for belt slipping, jumping, lateral movement or abnormal noise.
  • Confirm the alternator and all belt-driven accessories operate normally.

Product Description

1belt tensioner
