2012-2019 Ram 1500 5.7L V8/3.6L V6/4.7L V8/3.7L V6/3.0L V6 | Front Drive Shaft | 938090 - PHILTOP

2012-2019 Ram 1500 5.7L V8/3.6L V6/4.7L V8/3.7L V6/3.0L V6 | Front Drive Shaft | 938090 - PHILTOP

Front

Factory-Balanced

Corrosion-Resistant

4.3

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
64ISDSA0977US

Specifications

Brand
PHILTOP
Mounting Type
Flange + Cv Joint Mount
Position
Front
Fully Extended Length
33.11 in/841 mm
Fully Compressed Length
33.11 in/841 mm
Shaft Diameter
Φ63.5
Items Included
1x Drive Shaft - 938090
Surface Finish
Painted
Flange Shape
Square
Bolt Hole Quantity
4
Two-Piece Design
No
Adjustable Length
No
Tube Wall Thickness
0.08 in/2 mm
Shaft Material
Steel
Warranty Period
2-Year
Part Number
938090

Highlights

  • (Vehicle Fitments)Designed for Ram 2012-2018 1500 4WD(4/5/6-speed), 2019-2019 1500 Classic 4WD(6-speed).Please verify vehicle compatibility via Philtop's Confirmed Fit Tool and thoroughly read the product description prior to purchase
  • (Reference Number)938090,52123021AE,52123021AD
  • (Specifications)①Installation Position: Front Side; ②Extended Shaft Length: 33.11 inch; ③Compressed Shaft Length: 33.11 inch; ④Shaft Material: Steel; ⑤Shaft Diameter: Φ63.5; ⑥Shaft Wall Thickness: 0.079 inch; ⑦Length is measured end to end across the entire driveshaft; ⑧Mounting Type: Flange Mount + Ball Cage Mount; ⑨Flange Type: Square Shape
  • (High Quality)Pre-greased and maintenance-free. Rigorous quality testing verifies safety and performance for confident driving. Precision-engineered for perfect fitment and superior function, actively suppressing vibration and mechanical noise
  • (Drive with Pleasure)PHILTOP is dedicated to delivering a superior, safer, and more comfortable ride When your driveshaft needs replacement, trust our product—engineered as a direct OEM replacement to elevate your driving experience with enhanced smoothness and enjoyment

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2012 - 20132014 - 20162012 - 20162012 - 20132012 - 2013201320122012 - 201320132012 - 20132012 - 20132012201220122014 - 20182012 - 20132014 - 20162013 - 20162012 - 20132012 - 20162019
MakeRamRamRamRamRamRamRamRamRamRamRamRamRamRamRamRamRamRamRamRamRam
Model150015001500150015001500150015001500150015001500150015001500150015001500150015001500 Classic
TrimBig HornExpressExpressLaramieLaramie LonghornOutdoorsmanOutdoorsmanOutdoorsmanSLTSLTSLTSTSTSTSpecial ServiceSportTradesmanTradesmanTradesmanTradesmanSpecial Service
Engine5.7L V83.6L V65.7L V85.7L V85.7L V83.6L V64.7L V85.7L V83.6L V64.7L V85.7L V83.7L V64.7L V85.7L V85.7L V85.7L V83.0L V63.6L V64.7L V85.7L V85.7L V8
Note---------------------

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm the driveshaft length, spline count, flange type, mounting pattern and number of sections.
  • Inspect the shaft tube, U-joints, splines, center support bearing and rubber cushions for damage or excessive play.
  • Measure driveshaft length with the vehicle at normal ride height, not with the suspension hanging freely.
  • Support the vehicle securely and keep the transmission and rear axle at approximately the same height.
  • Before removal, clearly mark the front and rear orientation, flange positions and section alignment. The driveshaft must not be installed backward.

Installation Steps

  • Step-1: Place the transmission in Neutral when rotation is required, secure the wheels and support the driveshaft.
  • Step-2: Loosen the rear flange bolts gradually in a diagonal sequence.
  • Step-3: Disconnect the rear flange, center support bearing and front connection. Keep the driveshaft supported horizontally.
  • Step-4: Cap the transmission and differential openings immediately to prevent fluid leakage and contamination.
  • Step-5: Install the front end in the correct direction and align all previously made orientation and phase marks.
  • Step-6: Install the center support bearing without twisting or preloading its rubber cushion.
  • Step-7: Connect the rear flange and hand-start all bolts.
  • Step-8: Use a torque wrench to tighten all flange and support-bearing bolts to the vehicle manufacturer's specified torque. Do not use an impact wrench.

After Installation

  • Confirm all phase marks remain aligned and the driveshaft has not been installed front-to-rear.
  • Rotate the shaft by hand and check for binding, interference or abnormal joint movement.
  • Perform a low-speed road test, then gradually increase speed while checking for noise or vibration.
  • Reinspect all fasteners, support bearings and transmission or differential seals after the test drive.

Product Description

Drive Shaft AssemblyDrive Shaft Assembly
