2011-2025 Dodge Durango 3.6L/5.7L/6.4L/6.2L V8 | Rear Drive Shaft | 976884 - PHILTOP

2011-2025 Dodge Durango 3.6L/5.7L/6.4L/6.2L V8 | Rear Drive Shaft | 976884 - PHILTOP

Rear

Factory-Balanced

Corrosion-Resistant

4.5

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
67ISDSA1797US

Specifications

Brand
PHILTOP
Mounting Type
Cv Joint to Cv Joint
Position
Rear
Fully Extended Length
61.3 in/1557 mm
Fully Compressed Length
59.13 in/1502 mm
Shaft Diameter
Φ73/63.5
Items Included
1x Drive Shaft - 976884
Surface Finish
Painted
Two-Piece Design
Yes
Adjustable Length
Yes
Tube Wall Thickness
0.08 in/2 mm
Shaft Material
Steel
Warranty Period
2-Year
Part Number
976884

Highlights

  • (Vehicle Fitments)Designed for Dodge 2011-2025 Durango AWD (195 mm Axle).Please verify vehicle compatibility via Philtop's Confirmed Fit Tool and thoroughly read the product description prior to purchase
  • (Reference Number)976884,52123633AC,52123633AB,52123633AA
  • (Specifications)①Installation Position: Rear Side; ②Extended Shaft Length: 61.30 inch; ③Compressed Shaft Length: 59.13 inch; ④Shaft Material: Steel; ⑤Shaft Diameter: Φ73/63.5; ⑥Shaft Wall Thickness: 0.079 inch; ⑦Length is measured end to end across the entire driveshaft; ⑧Mounting Type: Ball Cage + Ball Cage; ⑨Design: Two-Piece; ⑩Adjustable Length for Custom Fit
  • (High Quality)High-strength forged steel and precision alloy joints give this driveshaft the resilience to handle dynamic forces on any terrain Every unit is factory-balanced to eliminate vibration and ensure long-term dependability
  • (Drive with Pleasure)PHILTOP is leading a smooth driving revolution with safer, more comfortable parts Our driveshaft, an exact OEM replacement, transforms your vehicle's ride quality for the better

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2011 - 20242011 - 20242011 - 20132011 - 201320112017 - 202520182020 - 20252023 - 202420112014 - 20162014 - 20152019 - 20252018 - 20252011 - 20252022 - 20232022 - 20252023 - 20252014 - 20152018 - 20212022 - 20242023 - 20242023 - 202420212023 - 2025202520252023 - 20242023 - 202520252012 - 202420182018 - 20212023 - 20242012 - 20192012 - 2019
MakeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodge
ModelDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurangoDurango
TrimCitadelCitadelCrewCrewExpressGTGTGT PlusGT PremiumHeatLimitedLimitedPursuitPursuitR/TR/T Hemi OrangeR/T PlusR/T PremiumRallyeSRTSRT 392SRT 392 PlusSRT 392 PremiumSRT HellcatSRT HellcatSRT Hellcat Brass MonkeySRT Hellcat HammerheadSRT Hellcat PlusSRT Hellcat PremiumSRT Hellcat Silver BulletSXTSXTSXT PlusSXT PlusSpecial ServiceSpecial Service
Engine3.6L V65.7L V83.6L V65.7L V83.6L V63.6L V65.7L V83.6L V63.6L V63.6L V63.6L V65.7L V83.6L V65.7L V85.7L V85.7L V85.7L V85.7L V83.6L V66.4L V86.4L V86.4L V86.4L V86.2L V86.2L V86.2L V86.2L V86.2L V86.2L V86.2L V83.6L V65.7L V83.6L V63.6L V63.6L V65.7L V8
Note
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)
w/ Sales Code DRH (195 mm Rear Axle)

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm the driveshaft length, spline count, flange type, mounting pattern and number of sections.
  • Inspect the shaft tube, U-joints, splines, center support bearing and rubber cushions for damage or excessive play.
  • Measure driveshaft length with the vehicle at normal ride height, not with the suspension hanging freely.
  • Support the vehicle securely and keep the transmission and rear axle at approximately the same height.
  • Before removal, clearly mark the front and rear orientation, flange positions and section alignment. The driveshaft must not be installed backward.

Installation Steps

  • Step-1: Place the transmission in Neutral when rotation is required, secure the wheels and support the driveshaft.
  • Step-2: Loosen the rear flange bolts gradually in a diagonal sequence.
  • Step-3: Disconnect the rear flange, center support bearing and front connection. Keep the driveshaft supported horizontally.
  • Step-4: Cap the transmission and differential openings immediately to prevent fluid leakage and contamination.
  • Step-5: Install the front end in the correct direction and align all previously made orientation and phase marks.
  • Step-6: Install the center support bearing without twisting or preloading its rubber cushion.
  • Step-7: Connect the rear flange and hand-start all bolts.
  • Step-8: Use a torque wrench to tighten all flange and support-bearing bolts to the vehicle manufacturer's specified torque. Do not use an impact wrench.

After Installation

  • Confirm all phase marks remain aligned and the driveshaft has not been installed front-to-rear.
  • Rotate the shaft by hand and check for binding, interference or abnormal joint movement.
  • Perform a low-speed road test, then gradually increase speed while checking for noise or vibration.
  • Reinspect all fasteners, support bearings and transmission or differential seals after the test drive.

Product Description

Drive Shaft AssemblyDrive Shaft Assembly

Reviews

4.5/5

Based on 6 reviews

567%
417%
317%
20%
10%

Tom_Handy_422

12/10/2025

Fast shipping and the item was very well protected in the box. I had a question about installation and the support team was super helpful. Really appreciate the good service and quick delivery.

Amanda_MomOfThree_457

10/05/2025

I was a bit nervous about the install, but this drive shaft fit like a glove. All the bolt holes lined up perfectly. It's a sturdy part that's working flawlessly. Way cheaper than buying from the dealer.
