2009-2014 Ford F-150 4.6L V8 | Fuel Pump Assembly | OE#9L3Z9A299F/SP2096M - PHILTOP

2009-2014 Ford F-150 4.6L V8 | Fuel Pump Assembly | OE#9L3Z9A299F/SP2096M - PHILTOP

Carbon Commutator

Precision Ceramic Resistor

Seal Included

4.6

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
61ISFUP3247US

Specifications

Brand
PHILTOP
Gasket or Seal Included
Yes
Pressure Sensor Included
No
Strainer Included
Yes
Fuel Level Sender Assembly Included
Yes
Resistance Ohms Empty
180.0 Ω
Resistance Ohms Full
10.0 Ω
Average Flow Rating
37 GPH
In Tank or External
In Tank
Lock Ring Included
No
Material
Metal, Plastic
Maximum Pressure
78.0 PSI
Outlet Outside Diameter
0.375 in
Outlet Quantity
2
Outlet Type
Quick Connect
Pump Structure
Turbine Impeller
Items Included
1x Fuel Pump Assembly - FG1316
Warranty Period
2-Year
OE Number
9L3Z9A299F,9L3Z9H307F
Part Number
SP2096M,P76468M,FG1316,5252305,USEP2545M,TU295,175GE

Highlights

  • #5,207,066 in Automotive (See Top 100 in Automotive)
  • #38,267 in Automotive Replacement Electric Fuel Pumps
  • [Purchase Verification Reminder] : This complete fuel pump kit contains the fuel pump, pressure sensor, float and tank seal and is ready for direct replacement. Please confirm the year/make/model of the vehicle you are purchasing before purchasing. You can refer to the fitment description on the product detail page or use the "Philtopconfirmedfit" in the upper left corner of the link to confirm.
  • Reference Number: TU295,5252305,175GE,USEP2545M,9L3Z9A299F,9L3Z9H307F,SP2096M,P76468M,FG1316
  • Related Parts: ① Fuel Pump, ② Strainer, ③ Seal Ring.
  • 20% Improved Fuel Delivery Efficiency: The commutator is made of carbon material, achieving an all-round performance leap compared with traditional copper commutators; it features superior electrical performance, shorter arc duration, stable current transmission, reduced motor energy consumption, and enhanced fuel delivery efficiency.
  • Superior Durability: The contacts are made of gold-palladium alloy with a melting point of up to 1450℃, featuring stable electrical conductivity, excellent corrosion resistance and wear resistance, and can achieve 1 million contact cycles without obvious damage.
