1991-1995/2001-2006 BMW 325i 2.5L L6/3.0L L6 | 5x120mm 72.56mm Center Bore M12x1.5 Thread Wheel Hub Accessory - PHILTOP

1991-1995/2001-2006 BMW 325i 2.5L L6/3.0L L6 | 5x120mm 72.56mm Center Bore M12x1.5 Thread Wheel Hub Accessory - PHILTOP

Durable

6061T6

12.9-Grade Bolts

5.0

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
28ISWSA4677US

Specifications

Brand
PHILTOP
Bolt Pattern
5x120mm
Wheel Bolt Pattern
5x120mm
Vehicle Bolt Pattern
5x120mm
Thread Size
M12x1.5
Center Bore
72.56
Hub-Centric Lip
Yes
Thickness
1inch
Outside Diameter
156
Inside Diameter
2.86 in/72.56 mm
Lug Patterns
5
Type
Wheel Spacer
Items Included
2x Hub-Centric Wheel Spacers,Thread Locker,Instruction Manual
ATV/UTV Compatible
No
Material
6061T6
Manufacturing Process
Forge
Recommended Torque
70-80 lb-ft
Bolt Grade
12.9
Warranty Period
2-Year

Highlights

  • [Wheel Spacers Specification] --- Bolt Pattern: 5x120mm ; | Thickness: 1 inch(25mm) ; | Thread Pitch: M12x1.5 ; | Hub Bore: 72.56mm ; | Recommended torque: 70-80 ft/lbs. !!! Note: If the length of the vehicle bolts exceed the thickness of the wheel adapters, you need to cut the vehicle bolts
  • [Vehicle Application] --- The 5x120 Wheel Spacer set replacement for 2003-2016 BMW Z4; 1988-2001 BMW 750iL; 1993-2001 BMW 740iL; 1985-1993 BMW 535i; 1992-1999 BMW 318is; BMW 318i; 2005-2012 BMW 120i; 2004-2010 BMW 525i; BMW 530i; 1982-1988 BMW 528e; 1989-1995 BMW 525i; 1996-2002 BMW Z3; 2008-2013 BMW 335i; BMW 328i; 2008-2013 BMW M3; BMW 135i; BMW 128i; 1994-1999 BMW M3; 2001-2006 BMW 330i; BMW 330Ci; BMW M3; BMW 325i; BMW 325Ci; 1987-1992 BMW 735i; 2006-2011 BMW 323i; 1985-1989 BMW 6
  • [High Quality] ---5x120 Wheel Spacer is truly forged from lightweight anodized 6061-T6 aircraft-grade aluminum alloy, the surface anodized coating can protect the metal surface from environmental erosion under extreme conditions. CNC precisely machined, with pre-installed heat treated 12.9 grade carbon steel studs, 7-10 times the corrosion resistance of similar products. The installation fit more better, so as to prevent wheel vibration and maintain the stock driving
  • [Aggressive Driving Experience] --- These 5x120 Wheel Spacers can move your wheels further out from the wheel hub, allow for larger tire installation to the vehicle. Installing the wheel spacers can fix brake caliper clearance issues, correct tire friction issues, increase cornering stability, give your vehicle a more aggressive stance
  • [Professional Services] --- Before placing an order, confirm compatibility by entering the year, make, and model in the PhiltopAuto suitability filter in the upper left corner. --- IMPORTANT SAFETY ADVISORY --- : Torque lug bolts/nuts to manufacturer specifications. Check and re-torque all hardware after 25-50 miles. See Product Description for additional install information

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year201120082009 - 20112012 - 201320082009 - 20112012 - 201320131992 - 19931994 - 19951996 - 19981992 - 19931994 - 19951996 - 199719951996 - 199920001998 - 199920001998 - 19992001 - 200619911992 - 1993199419952001 - 2005200619911991 - 19952001 - 200520062000201220131996 - 200020072008 - 2011201220132009 - 20111996 - 19992007 - 20082001 - 20062001 - 20022003 - 20062001 - 20062009 - 20112007 - 20112012 - 20132009 - 201120112012 - 20132007 - 20081985 - 19861989 - 19952004 - 20052006 - 200719932006 - 20071982 - 19882008 - 20102009201020082004 - 20071994 - 19952006 - 20071983 - 19842008 - 20101985 - 19932009 - 2010198820081994 - 19952004 - 20052006 - 201020101983 - 19841985 - 198920042005200620072008 - 20101987 - 19921988 - 1990199119921993 - 1995199719981999 - 20011993 - 1995199619971998 - 20011988 - 19941995 - 199619971998 - 2001199419951996 - 199719941995199319941995 - 19971991199219871986 - 19871988 - 1990199119951996 - 19992001 - 20062008 - 20112012 - 2013199519881991 - 19932006 - 20101987 - 19882006 - 200720082009 - 20102013 - 20152012 - 20152013 - 20151999 - 20002001 - 20021999 - 20021998 - 20021996 - 19981999 - 20021997 - 20002001 - 20022003 - 20052003 - 20052006 - 20082006 - 20082006 - 20082006 - 20082006 - 20082012 - 201620092010 - 201120092010 - 20162011 - 20162003200120022003
MakeBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMWBMW
Model1 Series M128i128i128i135i135i135i135is318i318i318i318is318is318is318ti318ti323Ci323i323i323is325Ci325i325i325i325i325i325i325iX325is325xi325xi328Ci328i328i328i328i328i328i328i328i xDrive328is328xi330Ci330i330i330xi335d335i335i335i xDrive335is335is335xi524td525i525i525i525iT525xi528e528i528i xDrive528i xDrive528xi530i530i530xi533i535i535i535i xDrive535is535xi540i545i550i550i GT633CSi635CSi645Ci645Ci650i650i650i735i735iL735iL735iL740i740i740i740i740iL740iL740iL740iL750iL750iL750iL750iL840Ci840Ci840Ci850CSi850CSi850Ci850Ci850Ci850i850iL6L7M3M3M3M3M3M3M3M3M5M5M5M6M6M6M6X1X1X1Z3Z3Z3Z3Z3Z3Z3Z3Z4Z4Z4Z4Z4Z4Z4Z4Z4Z4Z4Z4Z4Z8Z8Z8Z8
TrimBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseBaseLightweightBaseBaseBaseBaseBaseBaseBasesDrive28ixDrive28ixDrive35iCoupeCoupeM CoupeM RoadsterRoadsterRoadsterRoadsterRoadster2.5i3.0iCoupe 3.0siM CoupeM RoadsterRoadster 3.0iRoadster 3.0sisDrive28isDrive30isDrive30isDrive35isDrive35isDrive35isAlpinaBaseBaseBase
Engine3.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L61.8L L41.8L L41.9L L41.8L L41.8L L41.9L L41.8L L41.9L L42.5L L62.5L L62.5L L62.5L L62.5L L62.5L L62.5L L62.5L L62.5L L62.5L L63.0L L62.5L L62.5L L62.5L L63.0L L62.8L L62.0L L42.0L L42.8L L63.0L L63.0L L63.0L L63.0L L63.0L L62.8L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L L62.4L L62.5L L62.5L L63.0L L62.5L L63.0L L62.7L L63.0L L63.0L L63.0L L63.0L L63.0L L63.0L V83.0L L63.2L L63.0L L63.5L L63.0L L63.5L L63.0L L64.0L V84.4L V84.8L V84.4L V83.2L L63.5L L64.4L V84.4L V84.8L V84.8L V84.8L V83.5L L63.5L L63.5L L63.5L L64.0L V84.4L V84.4L V84.4L V84.0L V84.4L V84.4L V84.4L V85.0L V125.4L V125.4L V125.4L V124.0L V84.0L V84.4L V85.6L V125.6L V125.0L V125.0L V125.4L V125.0L V125.0L V123.5L L63.5L L62.3L L42.3L L43.0L L63.2L L63.2L L64.0L V84.0L V83.0L L63.5L L63.6L L65.0L V103.5L L65.0L V105.0L V105.0L V102.0L L42.0L L43.0L L62.8L L63.0L L63.2L L63.2L L61.9L L42.5L L62.8L L63.0L L62.5L L63.0L L63.0L L63.2L L63.2L L63.0L L63.0L L62.0L L43.0L L63.0L L63.0L L63.0L L63.0L L64.8L V85.0L V85.0L V85.0L V8
Note--
E82 & E88
--
E82 & E88
---
E36
E36
-
E36
E36
E36
E36
25mm 5x120
E36
E46
25mm 5x120
E46
25mm 5x120
25mm 5x120 325iC Models
25mm 5x120
-
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
12 (mm) Bolt Mounting Dimension
-
25mm 5x120
-
25mm 5x120
12 (mm) Bolt Mounting Dimension
-
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
-
25mm 5x120
25mm 5x120
E90 & E92
E90 & E92
-
E90 & E92
E90 & E92
-
E90 & E92
--
E60
E60
-
E60
---
E60
-
E60
-
E60
-
E60
-
E60
-
E60
-
E60
E60
25mm 5x120
---
25mm 5x120
-
25mm 5x120
---
25mm 5x120
---
25mm 5x120
---
25mm 5x120
---
25mm 5x120
-
25mm 5x120
--
25mm 5x120
--
25mm 5x120
--
25mm 5x120 From 04011992;From 492;Thru 03311992
---
E36
E36
E36
E46
E90 & E92
-
E36
--
E60
--
25mm 5x120
----
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
25mm 5x120
-
25mm 5x120
-
25mm 5x120
----
25mm 5x120
-

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Measure and confirm the bolt pattern, center bore, thread size and spacer thickness before purchasing.
  • Check the stock stud length. Extended studs may be required if the original studs are too short.
  • Confirm adequate wheel-to-fender clearance.
  • Test-fit the spacer. It must sit completely flush against the hub or brake rotor with no gap.

Installation Steps

  • Step-1: Clean the Mounting Surfaces:Remove all rust, dirt, oil and grease from the hub, studs and mounting surfaces.
  • Step-2: Install the Inner Plate:Position the inner plate flush against the hub. Install the open-end lug nuts with the tapered ends facing the spacer.
  • Step-3: Check Stud Clearance:Make sure the nuts sit flush inside the inner plate. If the stock studs interfere with the adapter or wheel, shorten or replace them as required.
  • Step-4: Install the Outer Plate:Apply thread locker to the first 5–6 threads of the connecting bolts. Install the outer plate and torque the bolts to 50–55 ft-lb (68–75 N·m).
  • Step-5: Install the Wheel:Start all lug nuts by hand and tighten them evenly in a crisscross pattern with a torque wrench. Do not use an impact wrench.

After Installation

  • Confirm that the spacer, adapter and wheel sit completely flush with no gaps or interference.
  • Check that all fasteners are secure and the wheel rotates freely.
  • Recheck the adapter nuts and bolts after the first 50–100 miles.
  • Recheck and retorque every 3,000–5,000 miles.

Product Video

Product Description

Wheel Adapters & SpacersWheel Adapters & Spacers

Reviews

5.0/5

Based on 2 reviews

5100%
40%
30%
20%
10%

travis

02/21/2026

Verified buyer

Very light and durable. Fits perfectly on bmw e60. Only recommendation if using a spacer this big is to do a studded conversion on your hub versus using the extended lug bolts.

Angie H.

01/26/2025

Verified buyer

They look great and so far they havent had any issues.

FAQS

Hub-centric spacers use a center bore or lip to help center the wheel on the hub, while lug-centric designs rely mainly on the wheel fasteners. Use the design specified for your application.

Compare the spacer specifications with the vehicle hub and wheel, including bolt pattern, center bore, stud or bolt size, and thread pitch. All dimensions should match the intended application.

Please do not install the product. Take photos of the item, packaging and shipping label, then contact Philtop customer support as soon as possible for assistance.
