2013-2016 Ford Fusion 2.0L | Aluminum 3/4" Radiator | OE#DG9Z8005H/CU13321 - PHILTOP

2013-2016 Ford Fusion 2.0L | Aluminum 3/4" Radiator | OE#DG9Z8005H/CU13321 - PHILTOP

Leak-Resistant

4.5

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
2015CFK244PUS

Specifications

Brand
PHILTOP
Transmission Oil Cooler Included
No
Engine Oil Cooler Included
No
Core Thickness
3/4 in
Core Width
26-7/16 in
Core Height
17-5/16 in
Radiator Cap Included
No
Inlet Diameter
1-5/16 in
Outlet Diameter
1-5/16 in
Items Included
1x Radiator - CU13321, 1x Instruction Manual
Mounting Type
Cradle / Bottom Post
Core Material
Aluminium
Radiator Flow Type
Cross Flow
Warranty Period
2-Year
OE Number
DG9Z8005H,DG9Z8005C,DG9Z8005J,DG9Z8005E,FO3010317,DG9Z8005DCP,DG9Z8005B,DG9Z8005D,DG9Z8005K
Part Number
CU13321,13321,2219303,4113321,13321C,2219304,4113322,2432,13320,FO3010316,2426,RAD13320,3669,2433,FO3010320,3598,13322,SBR13321,8013321,RAD13321,100035,RAD13322,2247,13484,PR13321A,432604,SBR13320,RAD100,RAD166,813320,813321,1981200676,1981200677,A13321,0R013321A1CM,8013320,NR13320A,NR13321A,CR13320,CR13321,C13320,17788000045933657,C13321,0AFD6260,0AFD6496,A13322,RAD165,13320C,RAD97,RAD167,RAD96,4113320

Highlights

  • Compatible with: 2014-2016 Fusion, 2013-2016 MKZ, 2013 Fusion 2.5L, 2013 Fusion 2.0L, 2013 Fusion 2.0T, 2013 Fusion 1.6T, 2017 MKZ 2.0L, 2019-2020 Police Responder Hybrid, 2019-2020 SSV Plug-In Hybrid
  • OEM Replacement: DG9Z8005B, DG9Z8005C, DG9Z8005D, DG9Z8005E, DG9Z8005H, DG9Z8005J, DG9Z8005K
  • IATF16949 Certification: Designed with outstanding durability, in compliance with the original specifications, and suitable for direct replacement.
  • High-Efficiency Cooling: Engineered with a high-density aluminum core and multi-layer cooling fins, ensuring optimal heat dissipation and maintaining the engine's ideal operating temperature.
  • Easy and Quick to Install - Direct bolt-on OE fitment or replacement for factory unit, fast and easy installation without any drilling or modification.

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year2013 - 20162013 - 20162014 - 20162014 - 20162014 - 20162013 - 20142013 - 20162014 - 20162013 - 20162013 - 20162013 - 20162019 - 20202013 - 20162013 - 20162015 - 20162015 - 2016
MakeFordFordFordFordFordFordFordFordFordFordFordFordLincolnLincolnLincolnLincoln
ModelFusionFusionFusionFusionFusionFusionFusionFusionFusionFusionFusionPolice Responder HybridMKZMKZMKZMKZ
TrimEnergi SEEnergi TitaniumSS HybridSESESESESE HybridTitaniumTitanium HybridBaseBaseBaseBlack LabelBlack Label
Engine2.0L L42.0L L42.5L L42.0L L41.5L L41.6L L42.0L L42.5L L42.0L L42.0L L42.0L L42.0L L42.0L L43.7L V62.0L L43.7L V6
Note
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit
Main Unit

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm fitment: Compare mounting points, hose connections, and oil cooler ports with the original radiator.
  • Inspect components: Check the radiator, hoses, clamps, and seals for damage or leaks.
  • Check coolant: Inspect the coolant level and condition. Flush contaminated coolant before installing the new radiator.

Installation Steps

  • STEP 1 — Let the engine cool completely, then disconnect the negative battery cable. Never open the pressure cap while hot.
  • STEP 2 — Drain the coolant into a suitable container and flush the system as required.
  • STEP 3 — Disconnect hoses, applicable oil cooler lines, and fan wiring. Remove the fan assembly and radiator as required by the vehicle’s service procedure.
  • STEP 4 — Transfer required brackets and accessories. Install the new radiator and tighten fasteners to vehicle specifications.
  • STEP 5 — Reconnect hoses, cooler lines, and electrical connectors. Refill with the specified coolant, bleed trapped air, and fit the correct pressure cap.

After Installation

  • Check hose connections, cooler lines, and the cooling system for leaks.
  • Confirm normal engine temperature and proper cooling fan operation.
  • After the engine cools completely, recheck the coolant level and top up as needed.
  • Recheck for leaks after a short test drive.

Product Video

Product Description

radiatorradiator

Reviews

4.5/5

Based on 8 reviews

563%
425%
313%
20%
10%

Nancy_FirstCar_739

02/02/2026

Super quick delivery, and the radiator fit perfectly. Swapping it out was easier than I thought it would be. Highly recommend this for your Fusion.

Ashley_RoadTrip_629

01/12/2026

Solved my temperature issues immediately. The Fusion runs cool and steady. Installation was surprisingly easy, and the shipping was quick. Great buy.

FAQS

Please provide your order number, vehicle information, installation date, current mileage and a description of the issue. Photos, videos or inspection information may also help us review the claim.

Overheating may also involve low coolant, trapped air, a thermostat, water pump, cooling fan, cap, hose, sensor, or engine condition.

Check the coolant level, hose and cooler-line connections, mounting points, and operating temperature. Inspect for leakage again after the engine cools.
