1996-2001 GMC Jimmy 4.3L V6 | Aluminum 1" Radiator | OE#52472963/CU1826 - PHILTOP

1996-2001 GMC Jimmy 4.3L V6 | Aluminum 1" Radiator | OE#52472963/CU1826 - PHILTOP

Leak-Resistant

4.8

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
6820RAD096CUS

Specifications

Brand
PHILTOP
Transmission Oil Cooler Included
No
Engine Oil Cooler Included
Yes
Core Thickness
1 in
Core Width
15 in
Core Height
26-1/4 in
Radiator Cap Included
No
Inlet Diameter
1-5/16 in
Outlet Diameter
1-9/16 in
Items Included
1x Radiator - CU1825, 1x Instruction Manual
Mounting Type
Top Saddle / Bottom Pin
Core Material
Aluminium
Radiator Flow Type
Cross Flow
Warranty Period
2-Year
OE Number
52472963,15120548,52472964,52462548,52462549,15120549
Part Number
CU1826,CU1825,2219006,411826,1826C,2370,1826,RAD1826,8011826,GM3010227,GM3010229,CR1826,20678,431405,40356,40355,RA1131,RA1070,1826A,438072,2561,A1826,RA1130,1834,C1826,2560,OR1826,9535,0AAS2675,17788000045933812,9534,A182628P3,XTP450046

Highlights

  • Vehicle Fitment For: Manual For: 1996-2005 Blazer 1996-2001 Jimmy 1996-2003 S10 4.3L 1996-2003 Sonoma 4.3L 1997-2000 Hombre 4.3L (w/ EOC (Engine Oil Cooler)
  • Reference Number:CU1825, CU1826, 1826C, 2219006, 411826, 15120549, 52462548, 15120548, 52462549, 52472963, 52472964, 9535, 40355, 40356, 431405
  • Enhanced Package: Package come with 1x PHILTOP Radiator Complete Radiator and. Fixed foam in four corners for the purpose of fixing the radiator, no bending and no damage.
  • High-Efficiency Cooling: Engineered with a high-density aluminum core and multi-layer cooling fins, ensuring optimal heat dissipation and maintaining the engine's ideal operating temperature.
  • IATF16950 Certification: Authoritative certification, quality assurance

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year1996 - 199920051996 - 20041996 - 20011999 - 20012001 - 20052003 - 20051996 - 20031996 - 200319961999 - 20031996 - 200319962000 - 20011998 - 20001996 - 199920011996 - 20011996 - 20011996 - 20011996 - 20031996 - 20011996 - 20031997 - 20001997 - 2000
MakeChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletChevroletGMCGMCGMCGMCGMCGMCGMCGMCGMCGMCGMCIsuzuIsuzu
ModelBlazerBlazerBlazerBlazerBlazerBlazerBlazerS10S10S10S10S10JimmyJimmyJimmyJimmyJimmyJimmyJimmyJimmySonomaSonomaSonomaHombreHombre
TrimBaseBaseLSLTTrailblazerXtremeZR2BaseLSSSXtremeZR2BaseDiamond EditionEnvoySLSLSLESLSSLTSLSLESLSSXS
Engine4.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V64.3L V6
Note
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler
Radiator Cap Is Required;with Engine Oil Cooler

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm fitment: Compare mounting points, hose connections, and oil cooler ports with the original radiator.
  • Inspect components: Check the radiator, hoses, clamps, and seals for damage or leaks.
  • Check coolant: Inspect the coolant level and condition. Flush contaminated coolant before installing the new radiator.

Installation Steps

  • STEP 1 — Let the engine cool completely, then disconnect the negative battery cable. Never open the pressure cap while hot.
  • STEP 2 — Drain the coolant into a suitable container and flush the system as required.
  • STEP 3 — Disconnect hoses, applicable oil cooler lines, and fan wiring. Remove the fan assembly and radiator as required by the vehicle’s service procedure.
  • STEP 4 — Transfer required brackets and accessories. Install the new radiator and tighten fasteners to vehicle specifications.
  • STEP 5 — Reconnect hoses, cooler lines, and electrical connectors. Refill with the specified coolant, bleed trapped air, and fit the correct pressure cap.

After Installation

  • Check hose connections, cooler lines, and the cooling system for leaks.
  • Confirm normal engine temperature and proper cooling fan operation.
  • After the engine cools completely, recheck the coolant level and top up as needed.
  • Recheck for leaks after a short test drive.

Product Video

Product Description

RADIATOR11

Reviews

4.8/5

Based on 5 reviews

580%
420%
30%
20%
10%

Chris_GearHead_186

11/22/2025

My old S10 was always running a little warm, especially in summer. This new radiator fixed that problem completely. The temperature gauge stays right in the middle now, no matter what. Big improvement.

Kelly_SUV_Life_266

12/23/2025

The quality on this radiator is really impressive. It feels heavy-duty and well-made, much better than I expected for the price. It's a great upgrade for my Blazer and I feel confident in its performance.

FAQS

Installed or modified products may require additional review and may not qualify for a standard return. Please contact Philtop before removing or returning the product.

Many cooling systems require bleeding after refilling to remove trapped air. Follow the procedure specified for the vehicle.

Overheating may also involve low coolant, trapped air, a thermostat, water pump, cooling fan, cap, hose, sensor, or engine condition.
