2001-2003 Dodge Grand Caravan 3.3L | Fuel Pump Assembly | OE#5096149AB/P76032M - PHILTOP

2001-2003 Dodge Grand Caravan 3.3L | Fuel Pump Assembly | OE#5096149AB/P76032M - PHILTOP

Carbon Commutator

Precision Ceramic Resistor

Seal Included

0.0

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
6417FUP687ZUS

Specifications

Brand
PHILTOP
Gasket or Seal Included
Yes
Pressure Sensor Included
No
Strainer Included
Yes
Fuel Level Sender Assembly Included
Yes
Resistance Ohms Empty
1050.0 Ω
Resistance Ohms Full
70.0 Ω
Average Flow Rating
24 GPH
In Tank or External
In Tank
Lock Ring Included
No
Material
Metal, Plastic
Maximum Pressure
80.0 PSI
Outlet Outside Diameter
0.375 in
Outlet Quantity
2
Outlet Type
Quick Connect
Pump Structure
Turbine Impeller
Items Included
1x Fuel Pump Assembly - FG0483
Warranty Period
2-Year
OE Number
5096149AB,RL096149AB,RL101830AC,P614M,5101830AC,5018875AB,5018875AA,5101830AA,RL101830AB,5101830AB
Part Number
P76032M,FG0483,SP7146M,9533047,TU169,USEP7146M,5202550,216GE,E7146M,FP5252,PN3107,67688,150084,TNKSP7146M,D13111063TG,C0456M,830984,RE1029S,AFS1029S,M2246716,DFG0483,2920150,402P7146M,4010292

Highlights

  • Fitment: Compatible with [Dodge]2001-2003 Grand Caravan FLEX, 2001-2003 Caravan FLEX, [Chrysler]2001-2003 Town & Country FLEX, 2001-2003 Voyager FLEX.
  • Reference Number: 5096149AB, E7146M, P76032M, RL096149AB, FG0483, SP7146M, 5018875AA, 5018875AB, 5101830AA, RL101830AB, 5101830AB, RL101830AC, 9533047, TU169, FP5252, PN3107, 150084, P614M, USEP7146M, 5202550, 5101830AC, 2920150, 4010292, 830984, TNKSP7146M, 402P7146M, D13111063TG, 216GE, 67688, DFG0483, M2246716, AFS1029S, RE1029S, C0456M.
  • Related Parts: ① Fuel Pump, ② Strainer, ③ Seal Ring.
  • 20% Improved Fuel Delivery Efficiency: The commutator is made of carbon material, achieving an all-round performance leap compared with traditional copper commutators; it features superior electrical performance, shorter arc duration, stable current transmission, reduced motor energy consumption, and enhanced fuel delivery efficiency.
  • Superior Durability: The contacts are made of gold-palladium alloy with a melting point of up to 1450℃, featuring stable electrical conductivity, excellent corrosion resistance and wear resistance, and can achieve 1 million contact cycles without obvious damage.

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year20032002 - 200320032001 - 20032001 - 200220032001 - 20022001 - 200320032001 - 20032001 - 200320032002 - 200320012001 - 20032001 - 2003
MakeChryslerChryslerChryslerChryslerChryslerChryslerChryslerChryslerDodgeDodgeDodgeDodgeDodgeDodgeDodgeDodge
ModelTown & CountryTown & CountryTown & CountryTown & CountryTown & CountryTown & CountryVoyagerVoyagerCaravanCaravanCaravanGrand CaravanGrand CaravanGrand CaravanGrand CaravanGrand Caravan
TrimBaseELEXLXLXiLimitedBaseLXC/VSESportBaseELESSESport
Engine3.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V63.3L V6
Note----------------

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm the fuel-pump sound at key-on and test the fuse, relay, power supply and ground.
  • Check fuel pressure before confirming that the pump requires replacement.
  • Compare the connector, fuel ports, mounting points and fuel-level sensor with the original unit.
  • Work in a well-ventilated area away from flames, sparks and smoking.
  • Relieve fuel-system pressure and disconnect the negative battery cable.
  • Confirm that a new fuel-pump sealing ring is available.

Installation Steps

  • Step-1: Relieve fuel pressure and clean the area around the tank opening.
  • Step-2: Label and disconnect the fuel lines and electrical connector.
  • Step-3: Remove the retaining ring using the correct tool—never strike it with a steel tool.
  • Step-4: Carefully lift out the old module without damaging the float arm.
  • Step-5: Discard the old sealing ring and install a new one.
  • Step-6: Install the new module in the correct orientation and secure the retaining ring.
  • Step-7: Reconnect the fuel lines and electrical connector, ensuring every clip is locked.

After Installation

  • Cycle the ignition ON two or three times without starting to prime the fuel system.
  • Start the engine and inspect every connection for leakage or fuel odor.
  • Verify fuel pressure and fuel-gauge operation.
  • Stop the engine immediately if a leak or strong gasoline odor is detected.
  • Avoid regularly operating the vehicle with a very low fuel level, which may overheat the pump.
