Leak-Resistant

4.8

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
1031CFK261XUS

Specifications

Brand
PHILTOP
Transmission Oil Cooler Included
Yes
Engine Oil Cooler Included
No
Core Thickness
1-1/4 in
Core Width
27-3/16 in
Core Height
19-7/8 in
Radiator Cap Included
No
Inlet Diameter
1-3/4 in
Outlet Diameter
1-3/4 in
Items Included
1x Radiator - CU2609, 1x Instruction Manual
Mounting Type
Top / Bottom Pin
Core Material
Aluminium
Radiator Flow Type
Down Flow
Warranty Period
2-Year
OE Number
2L1Z8005DG,2L1Z8005DD,H2MZ8005AC,2L1H8009DF,2L1Z8005FB
Part Number
CU2609,412609,2219631,2609C,FO3010242,A2609,C2609,KLI2609,9439,433834,SBR2609,REA412609A,CR2609,RA2609C,SBR2609V,PR2609A,PR2609F,NR2609C,AM2609,CUC2609,CRS2609,BES2609,1981200602

Highlights

  • Vehicle Fitment: 2002-2004 Expedition, 2003-2004 Navigator
  • Reference Number: 2L1H8009DF, 2L1Z8005DD, 2L1Z8005DG, 2L1Z8005FB, H2MZ8005AC
  • Product Dimension - Core Width: 27-3/16 in ,Core Height: 19-7/8 in ,Core Thickness: 1-1/4 in ,Inlet Diameter: 1-3/4 in ,Outlet Diameter: 1-3/4 in
  • IATF17061 Certification: Authoritative certification, quality assurance
  • Feature: Built with high density multi-Lowered fins for maximum cooling efficiency

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year200220032004200220032004200420042004200220032004200220032004200420042003 - 2004
MakeFordFordFordFordFordFordFordFordFordFordFordFordFordFordFordFordFordLincoln
ModelExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionExpeditionNavigator
TrimEddie BauerEddie BauerEddie BauerEddie BauerEddie BauerEddie BauerNBXNBXXLSXLTXLTXLTXLTXLTXLTXLT SportXLT SportBase
Engine4.6L V84.6L V84.6L V85.4L V85.4L V85.4L V84.6L V85.4L V84.6L V84.6L V84.6L V84.6L V85.4L V85.4L V85.4L V84.6L V85.4L V85.4L V8
Note
Downflow Unit;From Mar/2002
Downflow Unit
Downflow Unit;To Sep/2003
Downflow Unit;From Mar/2002
Downflow Unit
Downflow Unit;To Sep/2003
Downflow Unit;To Sep/2003
Downflow Unit;To Sep/2003
Downflow Unit;To Sep/2003
Downflow Unit;From Mar/2002
Downflow Unit
Downflow Unit;To Sep/2003
Downflow Unit;From Mar/2002
Downflow Unit
Downflow Unit;To Sep/2003
Downflow Unit;To Sep/2003
Downflow Unit;To Sep/2003
Downflow Unit

How to Install?

Installation Manual Download

User manual (PDF)
Download

Checks Before Installation

  • Confirm fitment: Compare mounting points, hose connections, and oil cooler ports with the original radiator.
  • Inspect components: Check the radiator, hoses, clamps, and seals for damage or leaks.
  • Check coolant: Inspect the coolant level and condition. Flush contaminated coolant before installing the new radiator.

Installation Steps

  • STEP 1 — Let the engine cool completely, then disconnect the negative battery cable. Never open the pressure cap while hot.
  • STEP 2 — Drain the coolant into a suitable container and flush the system as required.
  • STEP 3 — Disconnect hoses, applicable oil cooler lines, and fan wiring. Remove the fan assembly and radiator as required by the vehicle’s service procedure.
  • STEP 4 — Transfer required brackets and accessories. Install the new radiator and tighten fasteners to vehicle specifications.
  • STEP 5 — Reconnect hoses, cooler lines, and electrical connectors. Refill with the specified coolant, bleed trapped air, and fit the correct pressure cap.

After Installation

  • Check hose connections, cooler lines, and the cooling system for leaks.
  • Confirm normal engine temperature and proper cooling fan operation.
  • After the engine cools completely, recheck the coolant level and top up as needed.
  • Recheck for leaks after a short test drive.

Product Video

Product Description

RADIATOR11

Reviews

4.8/5

Based on 4 reviews

575%
425%
30%
20%
10%

Mike from Texas_729

12/19/2025

Installation was a breeze, didn't have any problems fitting it in. And the shipping was incredibly fast, got it in just a couple of days. Impressed with the whole process.

AutoMom_2019_739

12/04/2025

Looks and feels like a factory part, honestly. The craftsmanship is top-notch, and the price was surprisingly low for something this good. Definitely a great value.

FAQS

Stop the installation and contact Philtop customer support. Please provide your vehicle information, order number and photos of the original and received parts so we can help review the fitment.

Minor fin movement can occur during handling and may not affect normal operation. Do not install the radiator if the tubes, tanks, or mounting points are damaged.

Many cooling systems require bleeding after refilling to remove trapped air. Follow the procedure specified for the vehicle.
