2000 Nissan Maxima 3.0L V6 | 6 PC Ignition Coil | OE#224482Y007/UF348 - PHILTOP

2000 Nissan Maxima 3.0L V6 | 6 PC Ignition Coil | OE#224482Y007/UF348 - PHILTOP

Quick Ignition Response

High-Grade Insulation

Built to Last

4.8

Check if this fits your vehicle

Select a vehicle to check this product.

SKU:
36ISIGC3337US

Specifications

Brand
PHILTOP
Items Included
3x Ignition Coil - UF348 3x Ignition Coil - UF363
Type
Pen-Type
Quantity
6
Color
Black
Pin Count
3
Warranty Period
2-Year
OE Number
224482Y007,224482Y006,2244824015,224482Y000,224482Y005,224482Y001,224482Y05,224482Y00
Part Number
UF348,UF363,6734004,GN10431,E378,E393,C531,6734002,48911,GN10670,48665,C532,UF363T,UF348T,2IGC0373,SKIC010,2IGC0268,E362,UF332,UF586,6734003,UF332T,U5110,U5111,E1086,230035571,C1267,5C1163,C1266,5C1162,IC478,50068,1415104,345A,IC462,CUF348,F562,IGC0026,CUF363,5036,C758,6734005,5035,368035,50067,U5113,IC478SB,CLS1039,1788523,470002,72938026001,72938026500,CN22,362030,CLS1026,COP202,921X2022,72938026047,72938026,72938025694,1415103,1415103H,1415174H,2505520120,1788534,E378P,IC666,1813814,72938025,COP201,921X2045,362033,72938008001,72938008047,72938008694,230211,CN20,48333,230035611,IC493SB,E393P,92387,1415104H,1415172,1415172H,2505258553

Highlights

  • [Vehicle Fitment]:Compatible With [INFINITI] 2000-2000 I30 [Nissan] 2000-2000 Maxima
  • Reference Number:1415103,1415103H,1415104,1415104H,1415172,1415172H,1415174H,1788297,1788298,1788523,1788534,1813814,19140142,1IC211,2244824015,224482Y00,224482Y000,224482Y001,224482Y005,224482Y006,224482Y007,224482Y010,224482Y015,224482Y05,230035571,230035611,230211,230221,230234,250067,250068,2505258553,2505520120,250592387,250592388,2IC156,2IGC0268,2IGC0373,2T6,2T7,345A,354A,354B,362030,362033,368030,368035,470002,48333,48665,48911,50067,50068,5035,5036,521657,521658
  • Efficient work:Automotive replacement ignition coil | Fast ignition within 0.1-0.2 seconds | 140 ° C high temperature corrosion resistance | RF interference protection | 6500Mi longer lifespan | High voltage output | Smooth engine operation.
  • Easy to install: Quick and easy installation; Perfect match for the original vehicles. Please check the compatibility at the top of the page to confirm match your vehicle.
  • [Vehicle Fitment]:Compatible With [INFINITI] 2000-2000 I30 [Nissan] 2000-2000 Maxima

Compatible Vehicles

Check if this fits your vehicle

Vehicle(s) Fit Information

Year20002000200020002000
MakeINFINITIINFINITINissanNissanNissan
ModelI30I30MaximaMaximaMaxima
TrimBaseTGLEGXESE
Engine3.0L V63.0L V63.0L V63.0L V63.0L V6
Note-----

How to Install?

Installation Manual Download

User manual (PDF)
Download

Related Diagnostic Codes

  • P0300-Random/multiple-cylinder misfire — inspect the spark plugs, ignition coils, wiring and fuel system.
  • P0301–P0306-Specific-cylinder misfire — inspect the plug, coil and wiring for the indicated cylinder.
  • P0350-Ignition-coil primary/secondary circuit fault — check coil resistance, connectors and wiring.
  • P0351–P0356-Specific ignition-coil circuit fault — inspect the corresponding coil circuit and wiring.

Checks Before Installation

  • Confirm the ignition coils and spark plugs match the vehicle and original parts.
  • Check that the battery voltage meets the vehicle specification; the manual recommends at least 12.4V with the engine off.
  • Inspect the coil housings, connectors and wiring for cracks, corrosion or damage.
  • Check the spark-plug wells for oil, carbon deposits or debris.
  • Allow the engine to cool completely before removing the spark plugs.
  • Confirm the specified spark-plug gap and installation torque in the vehicle service manual.

Installation Steps

  • Step-1: Disconnect the Battery: Switch off the ignition and disconnect the negative battery cable to prevent short circuits or accidental starting.
  • Step-2: Remove the Old Parts: Label the connectors when necessary, unplug and remove the ignition coils, then clean around each spark-plug well before removing the plugs.
  • Step-3: Check the New Spark Plugs: Confirm the correct model and measure the electrode gap with a feeler gauge. Do not install dropped or damaged spark plugs.
  • Step-4: Install and Torque the Spark Plugs: Thread each spark plug fully by hand to prevent cross-threading. Then tighten it with a torque wrench to the vehicle manufacturer’s specified torque. Do not overtighten.
    Gasket seat and tapered seat spark plugs compared

    Gasket Seat Spark Plug: Uses a crush gasket to seal against the cylinder head.

    Tapered Seat Spark Plug – No Gasket: Uses the tapered metal seat to seal directly against the cylinder head.

  • Step-5: Complete the Installation: Install the ignition coils, tighten the mounting bolts to specification, fully seat every connector and reconnect the negative battery cable.

Spark Plug Torque Reference

Spark Plug ThreadRecommended Torque
18 mm (M18)35–40 N·m (25.8–29.5 lb-ft)
14 mm (M14)25–30 N·m (18.4–22.1 lb-ft)
12 mm (M12)15–20 N·m (11.1–14.8 lb-ft)
10 mm (M10)10–12 N·m (7.4–8.9 lb-ft)
8 mm (M8)8–10 N·m (5.9–7.4 lb-ft)
Tapered Seat – No Gasket10–20 N·m (7.4–14.8 lb-ft)

Important: This table is for general reference only. Required torque varies by spark-plug design, seat type and cylinder-head material. Always follow the vehicle service manual or spark-plug manufacturer’s specification when available.

After Installation

  • Clear historical fault codes with an OBD-II scanner.
  • Start the engine and let it idle for several minutes.
  • Confirm smooth idle, normal acceleration and no misfire or unusual vibration.
  • Check that the malfunction indicator light remains off.
  • Perform a short road test, then rescan for returned fault codes.

Product Video

Product Description

1coil pack

Reviews

4.8/5

Based on 4 reviews

575%
425%
30%
20%
10%

Steve_DIYer_681

11/06/2025

Came in a secure box and arrived ahead of schedule. I had a question about the connector and support was super helpful. Very pleased with my purchase.

Nancy_FirstCar_978

06/21/2026

Installation was pretty simple, just a few bolts and connectors. They fit perfectly and my car is running smoother than it has in years. Much cheaper than buying from the auto parts store.
